Description
Our new oil cooler for your Harley-Davidson® Softail is here and best in the USA. Drop your motorcycle oil temp up to 50 degrees and save your bike from over heating!
- Fits Softail Frames 2000-2017 without ABS brake components in the middle of the frame. See our SIde Mount options if you have ABS brakes
- Beautiful Chrome or Powder Coated Black Grill Cover hide and protect the heat exchanger and fans
- 3.0 Oil Adapter and Thermal Switch with waterproof connectors automatically turns on the powerful dual fans when your oil reaches 210 degrees and they stay on until the oil is cooled to 185 degrees. UltraCool’s goal is to keep your oil at the optimal temperature of between 200 and 230 degrees.
- 3.0 Specially designed aluminum heat exchanger with turbulators for maximum heat dissipation
- 3.0 Sealed Waterproof IP68 Dual Fans producing an amazing 220 CFM of airflow
- 3.0 plug and play wiring harness with relay and waterproof connectors that all connects to the battery under the seat for simple installation.
- 3.0 Black nylon coated stainless steel braided oil lines with AN6 fittings.
- 3.0 L.E.D. indicator light indicates when the fans are operating.
- LED mount included in kit.
- Black or Chrome 1″ clamp handlebar LED mounts sold separately.
- Special designed Oil Line Fitting Wrench and detailed instructions included.
 You may also need:
- Check out these electrical connectors you may need: #SMB-127 and SMB-Y129Â
- Check out these Oil Filters for additional cooling: PCS4B, PCS4C, and PCS4BC
Get a full 1 year parts only warranty from date of purchase.
Buy today!
*Will not work with ABS brake system located between the front down tubes and above the regulator.
*2000 year models need special mounting bracket
*Warning: Could cause damage when installed on lowered, large front fender or tire, non-maintained or modified suspensions.
